  • RG 58 C/U COAX 10 METERS with SO239 Plugs

RG 58 C/U COAX 10 METERS with SO239 Plugs

  • Brand: Wire Antennas UK
  • Product Code: RG 58 C/U 10 METERS with SO239 Plugs
  • Availability: 11
  • Short Description: Our best quality Military specification RG58 coax cable 10 meters with 2 SO239 connectors ready soldered. Tinned conductors - suitable for marine and outdoor use Specifications: Attenuation per 10 Metres 10 MHz - 0.45dB 50MHz - 1.3dB 100MHz- 1.5dB 200MHz - 2.5dB 1 GHz - 5.6dB Outer Diameter - 4.95mm Velocity Factor - 66% Capacitance PF/M: 100 Inner conductor 19/0.18mm Screen OD: 3.3mm

  • £16.50

  • Ex Tax: £16.50

0 reviews / Write a review

The RG 58 C/U  is a Coaxial Communication Cable stranded (19 x 0.18) tinned copper inner conductor, PE dielectric, braid outer conductor and black PVC jacket. Used for low and high power radio frequency (RF) connections.


  • CPR: Eca
  • 100pF/m Conductor to shield nominal capacitance
  • 66% Nominal velocity of propagation
  • 52R/km Maximum DC loop resistance
  • -15 to +70°C Operating temperature range
  • SO239 Plugs
